Model Overview
The CRF1100L Africa Twin Adventure Sports shares the frame, engine and riding position of the off-road focussed CRF1100L Africa Twin but has a role very much of its own: to offer riders real continent-crossing long-haul ability and practicality both on and off-road. This comes in the shape of a large 24.8L fuel tank, extensive wind protection (from both the fairing and fairing side panels), height-adjustable screen, large engine sump guard, aluminium rear carrier plus tubeless wheels and tyres. ACC charger and heated grips are also standard fit.
There’s 75kW power with 105Nm torque available from the1,084cc parallel twin cylinder engine, while the steel frame is the foundation of its handling prowess; it also uses a bolt-on bolt-on aluminium subframe. The aluminium swingarm references that of the CRF450R moto-crosser.
A six-axis Inertial Measurement Unit (IMU) controls not only the 7-level HSTC but also 3-level Wheelie Control, cornering ABS (with off-road setting), Rear Lift Control and DCT cornering detection. There are four default riding modes: URBAN, TOUR, GRAVEL and OFF-ROAD.
For cutting edge suspension damping front and rear the Africa Twin Adventure Sports is also available with Showa EERA™ as an option. Four default modes – SOFT, MID, HARD and OFF-ROAD – cover every type of riding situation, and there’s a USER mode for further fine-tuning. Rear spring preload can also be adjusted while stationary.
Tailored for complete control, the riding position features a slim-section seat and high-set handlebars. Dual LED Daytime Running Lights (DRL) feature three-stage Cornering Lights – that automatically adjust the field of illumination depending on the lean angle, giving optimum visibility for improved safety. Cruise control and heated grips are standard-fit. A full colour Multi Information Display (MID) 6.5-inch TFT touch screen brings immersive engagement with the machine’s systems, plus Apple CarPlay®, Android Auto® and Bluetooth connectivity.
For 23YM the CRF1100L Africa Twin Adventure Sports will be available in the following paint options:
- **NEW** Mat Iridium Gray Metallic
- Pearl Glare White
Styling & Equipment
- Protective bodywork with compact, height-adjustable screen
- 8L fuel tank, aluminium insert panels, rear rack and engine bash plate
- Daytime Running Lights (DRL) with Cornering Lights
- Cruise control, heated grips and ACC charger
- Multi Information Display (MID) 6.5-inch TFT touch screen
- Apple CarPlay® and Android Auto® allow use of a smartphone through the MID
Engine
- 1,084cc twin-cylinder engine gives 75kW peak power and 105Nm peak torque
- Unicam 8-valve head and semi-dry sump
- Variable Exhaust Control Valve (ECV) offers an engaging low-rpm sound and high-rpm performance
Engine & Chassis Management Electronics
- IMU-managed HSTC intervention levels have focus on off-road use
- Wheelie Control features 3 levels and IMU management
- Four riding modes: TOUR, URBAN, GRAVEL and OFF-ROAD
- Two USER modes allow for complete riding modes customisation
Dual Clutch Transmission
- Easy and direct’ system offers super-fast gear changes in either Manual Transmission (MT) or Automatic D and S modes
- S mode (with 3 levels) revs higher and downshifts sooner than D, for more aggressive riding
- G switch improves rear wheel traction when off-road
- Incline detection adapts shift pattern depending on gradient
- IMU allows corning detection function for improved shift timings
- Designed for smooth handling at pull-away and in lower gears
Chassis
- Lightweight frame, with bolt-on aluminium subframe and light, rigid CRF450R-style swingarm for outstanding rear wheel traction and feel
- A six-axis Inertial Measurement Unit is housed in the centre of the machine
- Cornering ABS provides sure-footed feel and features an off-road setting
Accessories
A range of Honda Genuine Accessories is available for the Africa Twin Adventure Sports, available individually as well as in selected packs for convenience.
Accessories are available in both a Super Pack and a Travel Pack for convenience.
The Super Pack has been developed to enhance both long distance comfort and increase luggage capacity, with two luggage versions available: aluminium and plastic.
The Travel Pack maximises the Africa Twins long distance travelling abilities. Like the Super Pack, the Travel pack is also available in two versions, aluminium and plastic
Additional accessories are also available and include:
- Low (825-845mm) or high (870-895mm) seat options
- Full sticker protection
- Slip-on SC-Project muffler
- 38L top box
- 3L tank bag
Technical Specification
|
ENGINE |
|
|
Type |
SOHC liquid-cooled 4-stroke 8-valve parallel twin with 270° crank and Uni-cam |
|
Displacement |
1084cc |
|
Bore & Stroke |
92mm x 81.5mm |
|
Compression Ratio |
10.1:1 |
|
Max. Power Output |
75kW at 7500rpm |
|
Max. Torque |
105Nm at 6250rpm |
|
Noise Level |
L-urban73.2dB, L-wot78.9dB – MT; |
|
Oil Capacity |
4.8/4.3 (5.2/4.7 DCT) |
|
FUEL SYSTEM |
|
|
Carburation |
PGM-FI |
|
Fuel Tank Capacity |
24.8L |
|
CO2 Emissions |
112g/km MT 110g/km DCT |
|
Fuel Consumption |
4.9L/100km (20.4km/L) MT 4.8L/100km (20.8km/L) DCT |
|
ELECTRICAL SYSTEM |
|
|
Starter |
Electric |
|
Battery Capacity |
12V-6Ah Li-ion battery (20hr) |
|
ACG Output |
0.49kW/5000rpm |
|
DRIVETRAIN |
|
|
Clutch Type |
Wet, multiplate with coil springs, aluminium cam assist and slipper clutch DCT – 2 wet multiplate clutches with coil springs |
|
Transmission Type |
6 speed manual (6 speed DCT) |
|
FRAME |
|
|
Type |
Semi double cradle |
|
CHASSIS |
|
|
Dimensions (L´W´H) |
2330mm x 960mm x 1490mm (1545mm with screen in uppermost position) |
|
Wheelbase |
1575mm |
|
Caster Angle |
27.5° |
|
Trail |
113mm |
|
Seat Height |
850/870mm (low seat option 825mm, high seat option 895mm) |
|
Ground Clearance |
250mm |
|
Kerb Weight |
238kg (DCT 248kg) With Showa EERATM 240kg MT (DCT 250kg) |
|
SUSPENSION |
|
|
Type Front |
Showa 45mm cartridge-type inverted telescopic fork with dial-style preload adjuster and damping adjustment, 230mm stroke
EERATM – Showa Telescopic inverted fork with an inner tube diameter of 45mm, and Showa EERATM with compression and rebound dumping adjustments, 230mm stroke
|
|
Type Rear |
Monoblock aluminium swing arm with Pro-Link with Showa gas-charged damper, hydraulic dial-style preload adjuster and rebound damping adjustments, 220 mm rear wheel travel.
EERATM – Monoblock aluminium swing arm with Pro-Link with Showa gas-charged damper, hydraulic remote control preload adjuster and electric control unit with compression and rebound damping adjustments, 220 mm rear wheel travel |
|
WHEELS |
|
|
Type Front |
21M/C x MT2.15 wire spoke with aluminium rim |
|
Type Rear |
18M/C x MT4.00 wire spoke with aluminium rim |
|
Rim Size Front |
21″ |
|
Rim Size Rear |
18″ |
|
Tyres Front |
90/90-21M/C 54H (tubeless type) Bridgestone Battlax Adventurecross Tourer AX41T |
|
Tyres Rear |
150/70R18M/C 70H (tubeless type) Bridgestone Battlax Adventurecross Tourer AX41T |
|
BRAKES |
|
|
ABS System Type |
2 channel with IMU |
|
Type Front |
310mm dual wave floating hydraulic disc with aluminium hub and radial fit 4-piston calipers and sintered metal pads |
|
Type Rear |
256mm wave hydraulic disc with single piston caliper and sintered metal pads. 2-Channel with rear ABS off mode. |
|
INSTRUMENTS & ELECTRICS |
|
|
Instruments |
LCD Meter, TFT 6.5inch touch panel multi information display |
|
Security System |
Immobiliser, security alarm (optional) |
|
Headlight |
LED |
|
Taillight |
LED |
|
Electrics |
Daytime running lights, Bluetooth audio and Apple CarPlay®, Android Auto®, USB socket, auto turn signal cancel, cruise control, emergency stop signal, IMU, HSTC, cornering lights, wheelie control |
** Please note that the figures provided are results obtained by Honda under standardised testing conditions prescribed by WMTC. Tests are conducted on a rolling road using a standard version of the vehicle with only one rider and no additional optional equipment. Actual fuel consumption may vary depending on how you ride, how you maintain your vehicle, weather, road conditions, tire pressure, installation of accessories, cargo, rider and passenger weight, and other factors.
