Model Overview
The new CB125F is a serious small machine, whose development involved the filing of no fewer than 19 patent applications. Made at Honda’s Atessa facility in south east Italy it offers a huge jump in fuel economy from its air-cooled enhanced Smart Power (eSP) engine, with no loss of performance.
It’s also 11kg lighter, with a redesigned frame and an up-to-date, big-bike re-style; an LED headlight and revised digital dash are quality finishing touches. The 2021 CB125F will be available in the following colour options:
- Splendor Red
- Pearl Cool White
- Black
Chassis, Styling & Equipment
- New tubular steel frame saves 1.7kg; twin rear shocks are preload adjustable
- Sharp re-style adds big-bike presence and extra CB family DNA
- The nose fairing houses an LED headlight and digital dash
- Wet weight of 117kg is 8.6% lighter than the previous model
Engine
- New enhanced Smart Power (eSP) engine offers 27% extra fuel economy, with no loss of performance
- Low friction technologies include offset cylinder, needle bearings for the roller/rocker arms and piston oil jet
- ACG starter also generates electricity and contributes greatly to the engine’s 7kg weight loss
- 5-speed gearbox and sealed final drive chain
Technical Specifications
ENGINE |
|
Type |
Air cooled 4 stroke OHC single |
Displacement |
124cc |
No of Valves per Cylinder |
2 |
Bore & Stroke |
50 x 63.1mm |
Compression Ratio |
10.0:1 |
Max. Power Output |
8kW @7,500rpm |
Max. Torque |
10.9Nm @ 6,000rpm |
Noise level (dB) |
73.5dB(Lwot) 71.8dB(Lurban) |
Oil Capacity |
1L |
FUEL SYSTEM |
|
Carburation |
PGM-FI electronic fuel injection |
Fuel Tank Capacity |
11L |
Fuel Consumption (WMTC) |
66.7 Km/L |
CO2 Emissions WMTC |
34 g/km |
ELECTRICAL SYSTEM |
|
Battery Capacity |
12V-5A・h |
|
|
DRIVETRAIN |
|
Clutch Type |
Wet, multiplate with coil springs |
Transmission Type |
5 speed |
Final Drive |
Chain |
FRAME |
|
Type |
Tubular steel |
CHASSIS |
|
Dimensions (L´W´H) |
2015mm x 750mm x 1100mm |
Wheelbase |
1280mm |
Caster Angle |
26° |
Trail |
92.4mm |
Seat Height |
790mm |
Ground Clearance |
160mm |
Kerb Weight |
117KG |
Turning radius |
2.04m |
SUSPENSION |
|
Type Front |
31mm telescopic |
Type Rear |
Dual shocks – 5 stage preload |
WHEELS |
|
Type Front |
18in five spoke aluminium |
Type Rear |
18in five spoke aluminium |
Tyres Front |
80 / 100 18M/C |
Tyres Rear |
90 / 90 18M/C |
BRAKES |
|
System Type |
CBS |
Type Front |
240mm single disc with two piston caliper |
Type Rear |
130mm drum |
INSTRUMENTS & ELECTRICS |
|
Instruments |
Speedometer, milometer, fuel gauge, rpm counter, gear position indicator |
Headlight |
LED |
Taillight |
LED |
All specifications are provisional and subject to change without notice
Please note that the figures provided are results obtained by Honda under standardised testing conditions prescribed by WMTC. Tests are conducted on a rolling road using a standard version of the vehicle with only one rider and no additional optional equipment. Actual fuel consumption may vary depending on how you ride, how you maintain your vehicle, weather, road conditions, tire pressure, installation of accessories, cargo, rider and passenger weight, and other factors.
